Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service
  • Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service

Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service

Lugar de origen Jiangsu, China
Certificación ISO9001
Número de modelo 6063
Documento Manual del producto PDF
Detalles del producto
Nombre del producto:
Profile de aleación de aluminio
Tolerancia:
± 1%
Temperamento:
T5
Servicio:
De las partidas de las demás partidas
Aleación o no:
Es aleación
Tamaño:
personalizado
Resaltar:

customized aluminium alloy I beams

,

6063 extruded aluminium profiles

,

aluminium profile bending and cutting service

Condiciones de pago y envío
Cantidad de orden mínima
1
Precio
negotiable
Detalles de empaquetado
Paquete de exportación/paquete de caja de madera, etc.
Tiempo de entrega
3-15 días
Condiciones de pago
L/C, T/T, Western Union
Capacidad de la fuente
2000 toneladas/toneladas por mes
Descripción del Producto
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service
Product Introduction

6063 T5 aluminum I-beam is a very common aluminum alloy structural profile, which is manufactured through hot extrusion molding process. After heating the 6063 aluminum alloy ingot, it is forced to pass through an I-shaped mold to obtain continuous profiles, which are then cooled and aged to achieve the required mechanical properties.

Product Name 6063 I Beam Aluminium Alloy Profile
Model Number 6063
Temper T5
Size Customized
Tolerance +/-1%
Certificate ISO9001 or as required
Process bending, welding, precise cutting, punching, etc.
Surface Treatment Mill finished, mechanical polished, anodized, powder coated, sandblasted, electrophoresis, wooden grain, etc
Type beam formwork, etc.
Alloy Or Not Is Alloy
Price Terms FOB,CIF,CFR,EXW etc
Package Standard pallet with waterproof film, or according to your requirement.
Mechanical Property
Performanve Index Typical Value Describe
Tensile Strength ≥160Mpa Measure the ability of a material to resist fracture.
Yield Strength ≥110Mpa Measure the ability of a material to undergo permanent deformation. This is a key indicator for structural design.
Elongation ≥8% Measure the ductility of materials.
Hardness ≥60HV Vickers hardness value.
Product Details
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service 0
Packing and Shippment
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service 1 Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service 2
Application
  • The transportation sector is the main force, such as commercial vehicle chassis longitudinal beams, rail transit seat supports, and ship deck frames, which can reduce weight and consumption.
  • In industrial equipment, it is suitable for automation equipment main beams, heavy-duty shelf crossbeams, and forklift door frames, balancing load and resistance to oil/coolant corrosion.
  • Used in the field of architecture for lightweight exhibition hall load-bearing beams, glass curtain wall keels, and indoor ceiling supports, easy to install and weather resistant and aesthetically pleasing.
  • In new energy and special scenarios, it is commonly found in photovoltaic bracket main beams and energy storage equipment frames.
Factory Inventory
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service 3
Certification
Customized Shape Extruded I Beams 6063 Aluminium Alloy Profile Bending And Cutting Service 4
FAQ
Q: ARE YOU FACTORY OR TRADER?
A: Our company is a cold rolling manufacturer of magnetic stainless steel coil since 2016. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q: HOW TO GET A SAMPLE?
A: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q: HOW TO VISIT YOUR FACTORY?
A: Most of the main cities have flights to Wuxi; you can take flight to Wuxi Shuofang International Airport.
If you come from Shanghai, it will take 2 hours by flight (every day 5 flights).
If you come from Hongkong, it will take 1 hour by flight (every day 1 flight around noon time).
